Hardware description languages are used to compute the hardware structure of a circuit that efficiently produces the desired Boolean function output during digital circuit design. In other words, they are employed by logic synthesis tools to generate a netlist that specifies the components within the circuit and their interconnections. This generated netlist is then used for transistor-level circuit simulation and verification. Based on the results of these processes, design iterations are perfo

Logic gates are fundamental circuit elements that process input signals according to specific logical rules to produce a single output signal in digital systems. Inputs and outputs are represented by binary signals in two states (0 and 1). Therefore, logic gates operate in accordance with Boolean algebra. The functions of the gates are defined by truth tables and symbols, which show what the output will be for each possible input combination. Logic gates are used to perform the most basic functi
